| PART | MATERIAL |
| Body | Ductile iron QT450-10 |
| Disc | Ductile Iron+EPDM/NBR QT450-10+EPDM |
| Stem | Stainless Steel AISI 402 |
| Stem Nut | Brass(DN50-DN400) DI(DN450-DN600) |
| Bonnet | Ductile iron QT450-10 |
| Hexagon Bolt | Carbon Steel Chrome Plated |
| O Ring | EPDM/NBR |
| Handwheel | Ductile iron QT450-10 |
PRESSURE RATING : PN16
TEMPERATURE OPERATING RANGE : -20 to 110°C
END CONNECTION : ASME Class125/Class 150
BSEN1092-2 PN10/PN16 AS2129 Table D/Table E
JISB2239 10K/16K
OPERATOR : Handwheel.
Gate valves are best to use as fully open or fully closed
and not to be used for throttling.
